ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
Ezaugarri nagusiak
Stainless steel structure;Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
Pisuari buruzko iritziak eta proportzio motaren arabera, hainbat materialen proportzio desberdineko paketatutako pisu eskasia falta zaigu.
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Data
Hopper | Quick disconnecting hopper 25L |
Pisua egitea | 10 - 1000g |
Enbalatzeko zehaztasuna | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
Abiadura betetzea | 5 – 20 times per min |
Energia hornidura | 3P AC208-415V 50/60Hz |
Energia guztira | 2.25Kw |
Pisu osoa | 350kg |
Overall Dimensions | 1205×1010×2174mm |
